Nail‑free Riveting Machine F350

Specifications, applications and operation

Specification breakdown. The Nail‑free Riveting Machine F350 handles material thicknesses of 0.8–3.5 mm, max flange height 36 mm, with overall dimensions of 2200×1500×1600 mm, and weighs approximately 8.3 kg.

Typical applications. Riveting and corner-fastening machines complete the assembly of rectangular duct sections, joining four duct walls into a finished box. Pneumatic and hydraulic riveters install corner clips and TDF corners at high speed; clinch rivet machines like the F350 join sheet metal without any added fasteners, which is a clean solution for stainless and aluminium duct where fastener corrosion or galvanic mismatch is a concern.

How it works. Riveting and fastening machines join sheet metal components without welding. Hydraulic and pneumatic riveters install standard rivets at high cycle rates; clinch riveting joins two layers of sheet metal by progressively deforming them into an interlocked button, with no added fasteners required. Both methods are used at corners, brackets, stiffeners and TDF corner clips in duct assembly.

Quality, certification and after-sales. Like every machine in the SBKJ catalogue, this unit is built to ISO 9001:2015 quality management standards and CE marked for European conformity. The factory in Jiangyin, Jiangsu has been operating since 1995 and SBKJ holds 60+ invention and utility patents in HVAC ductwork machinery design. Each machine ships with a 12-month warranty on mechanical and electrical components, lifetime spare-parts availability, and 3–7 days of on-site installation supervision and operator training by an SBKJ engineer. Remote support is available via WhatsApp and email, with engineer response within 12 hours and technical troubleshooting within 72 hours.

Where this fits in your workshop

Cutting, bending and forming machines are the upstream stations of any duct workshop. Coil stock is sheared to length, scored and bent into the duct shape, and then handed off to the seam closer or the TDF former. On an SBAL-V auto duct line these operations are integrated into a single coil-to-duct line; on a manual or semi-auto workshop they are stand-alone stations operated by 2–4 staff. SBKJ supplies the full upstream set — coil line, plasma cutter, folder, beader, rollformer — either matched to one of our auto lines or as individual replacements for ageing equipment.

Pre-purchase checklist

Use this list when you write the enquiry or when you compare two suppliers. Each line is something an SBKJ engineer will want clarified before quoting.

• Maximum sheet thickness and width at the gauges you actually run
• Cutting accuracy — ±0.2 mm is the SBKJ commercial-line standard
• Tool life and sharpening interval at production volume
• Drive type — servo for accuracy, hydraulic for heavy gauge
• Workshop floor space and crane access for sheet handling
• Compatibility with your downstream seam closer and TDF former

Operator and maintenance notes. The Nail‑free Riveting Machine F350 is designed to be run by a single trained operator under normal conditions. Daily checks include lubrication of the forming rolls, inspection of the drive belts and chain tension, and a clean-down of the tool surfaces. Weekly checks add electrical cabinet inspection and a torque check on the main frame fasteners. SBKJ ships every machine with an English operator manual, a maintenance schedule and a recommended two-year spare parts kit. Operator training is included in the 7-day commissioning visit, and a refresher session can be booked at any time within the warranty period.
